VOOPOO PnP Replacement Coils
Genuine VOOPOO PnP coils in 17 core types, from a 0.15Ω mesh built for heavy cloud production down to a 1.2Ω MTL coil built for a tight, cigarette-like draw. Match the coil to your device's wattage range and how you actually vape — the full breakdown is below.
Before you order: check your device can actually reach the coil's rated wattage. A coil run below its minimum wattage delivers weak vapor and a burnt taste no matter how new it is.
Coil Options
| Core | Type | Resistance | Wattage Range | Style |
|---|---|---|---|---|
| VM6 | Mesh | 0.15Ω | 60-80W | DL |
| TW15 | Mesh | 0.15Ω | 55-70W | DL |
| VM5 | Mesh | 0.2Ω | 40-60W | DL |
| TW20 | Mesh | 0.2Ω | 40-55W | DL |
| VM1 | Mesh | 0.3Ω | 32-40W | DL |
| TW30 | Mesh | 0.3Ω | 28-36W | DL/RTL |
| VM3 | Mesh | 0.45Ω | 25-35W | DL |
| VM4 | Mesh | 0.6Ω | check tank manual | Half DL |
| TM1 | Regular | 0.6Ω | 20-25W | Half DL |
| DW60 | Regular | 0.6Ω | 18-23W | RDL |
| TM2 | Regular | 0.8Ω | 12-18W | Half DL |
| R1 | Regular | 0.8Ω | 12-18W | MTL |
| DW80 | Regular | 0.8Ω | 12-16W | MTL |
| R2 | Regular | 1.0Ω | 10-15W | MTL |
| TR1 | Regular | 1.2Ω | 10-15W | MTL |
| VM2 | Regular | 1.2Ω | check tank manual | MTL |
| RBA | Rebuildable | 0.25–2.0Ω | build your own | — |
Compatible With
VOOPOO Drag X • Drag S • Drag 4 • Drag Max • Drag H40 • Drag H80S Kit • Drag E60 Kit • Drag Baby Trio • Vinci • Vinci R • Vinci X • Vinci X2 • Vinci 2 • Vinci 3 Kit • Argus 40W • Argus Air • Argus Pro 80W • UForce-L Tank • V.SUIT • PnP Pod Tank • Navi
FAQ
| Q |
What's the difference between Mesh and Regular coils?
Mesh coils (the VM and TW series) heat more evenly across a wider surface, which usually means brighter flavor and a faster ramp-up. Regular coils use a classic wire-wrapped build and tend to run at lower wattage.
|
| Q |
How do I know if I want DL or MTL?
DL (direct lung) is a big, airy draw straight to the lungs, like pulling through a straw — that's the sub-0.5Ω coils at higher wattage. MTL (mouth to lung) is a tighter draw you hold in your mouth first, closer to a cigarette — that's 0.8Ω and up at lower wattage.
|
| Q |
Do I need to prime a new coil before using it?
Yes. Apply a few drops of e-liquid directly to the exposed wicking holes and let it sit 5-10 minutes before your first vape, so the cotton fully saturates. Firing a dry coil can scorch the wick immediately.
|
Sold as a single coil or in a 5-pack. For use by adults 21+.
